ASRock MB Sc LGA1151 H110 PRO BTC+, Intel H110, 2xDDR4, VGA, MINING

Socket (pätica):Socket 1151; Formát:ATX; Integrovaná grafická karta:Ano (CPU); Chipset:Intel; Typ pamäťového modulu:DDR4; PCI express 16x:1; Integrovaná LAN karta:1; Podpora RAID:Bez RAID podpory; Rozhranie:DVI.... viac
Bežná cena: 129.35  (-15%)
91.27 € bez DPH
Nie je skladom - opýtajte sa
109.52 €
ks
Vyberte si zvýhodnené balenie
Množstevné zľavy
Kód: 380373
EAN: 4717677333763
Záruka: 24 Měsíc(ů)
Výrobca: ASRock
Popis a parametre
Diskusia

ASRock MB Sc LGA1151 H110 PRO BTC+, Intel H110, 2xDDR4, VGA, MINING




  • Unique Feature

    ASRock Super Alloy
    - Sapphire Black PCB
    - High Density Glass Fabric PCB
    ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
    ASRock Live Update & APP Shop









  • CPU

    - Supports 7th and 6th Generation Intel® Core™ i7/i5/i3/Pentium®/Celeron® Processors (Socket 1151)
    - Supports CPU up to 91W
    - Digi Power design
    - 8 Power Phase design
    - Supports Intel® Turbo Boost 2.0 Technology






  • Chipset

    - Intel® H110






  • Memory

    - Dual Channel DDR4 Memory Technology
    - 2 x DDR4 DIMM Slots
    - Supports DDR4 2400/2133 non-ECC, un-buffered memory*
    - Supports ECC UDIMM memory modules (operate in non-ECC mode)
    - Max. capacity of system memory: 32GB*
    - Supports Intel® Extreme Memory Profile (XMP) 2.0
    - 15µ Gold Contact in DIMM Slots

    *7th Gen Intel® CPU supports DDR4 up to 2400; 6th Gen Intel® CPU supports DDR4 up to 2133.

    **Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation.





  • BIOS

    - 64Mb AMI UEFI Legal BIOS with multilingual GUI support
    - ACPI 5.0 Compliant wake up events
    - SMBIOS 2.7 Support
    - CPU, DRAM, PCH 1.05V Voltage multi-adjustment






  • Graphics


    - Supports Intel® HD Graphics Built-in Visuals : Intel® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel® InTru™ 3D, Intel® Clear Video HD Technology, Intel® Insider™, Intel® HD Graphics
    - Gen9 LP, DX11.3, DX12
    - HWAEncode/Decode: VP8, HEVC 8b, VP9, HEVC 10b (For 7th Gen Intel® CPU)
    - HWA Encode/Decode: VP8, HEVC 8b; GPU/SWEncode/Decode: VP9, HEVC 10b (For 6th Gen Intel® CPU)
    - Max. shared memory 1024MB**
    - Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
    - Supports Accelerated Media Codecs: HEVC, VP8, VP9
    - Supports HDCP with DVI-D Port
    - Supports Full HD 1080p Blu-ray (BD) playback with DVI-D Port
    *Intel® HD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.
    **The size of maximum shared memory may vary from different operating systems.





  • Audio

    - 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
    - Supports Surge Protection
    - ELNA Audio Caps

    *To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.





  • LAN

    - Gigabit LAN 10/100/1000 Mb/s
    - Giga PHY Intel® I219V
    - Supports Wake-On-LAN (Supported on Black PCIe Slots only)
    - Supports Lightning/ESD Protection
    - Supports Energy Efficient Ethernet 802.3az
    - Supports PXE






  • Slots

    - 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*
    - 12 x PCI Express 2.0 x1 Slots

    *Supports NVMe SSD as boot disk





  • Storage

    - 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug*
    - 1 x M.2 Socket, supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module

    *If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled.





  • Connector

    - 1 x Print Port Header
    - 1 x COM Port Header
    - 1 x TPM Header
    - 1 x Chassis Intrusion and Speaker Header
    - 1 x CPU Fan Connector (4-pin)*
    - 2 x Chassis Fan Connectors (4-pin)
    - 1 x 24 pin ATX Power Connector
    - 1 x 8 pin 12V Power Connector
    - 2 x PCIe Power Connectors-1 x SATA Power Connector
    - 1 x Front Panel Audio Connector
    - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
    - 1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports ESD Protection)

    *The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.





  • Rear Panel I/O

    - 1 x PS/2 Mouse Port
    - 1 x PS/2 Keyboard Port
    - 1 x DVI-D Port
    - 4 x USB 2.0 Ports (Supports ESD Protection)
    - 2 x USB 3.0 Ports (Supports ESD Protection)
    - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
    - HD Audio Jacks: Line in / Front Speaker / Microphone






  • Software and UEFI

    Software
    - ASRock APP Charger
    - ASRock XFast LAN*
    UEFI
    - ASRock Instant Flash

    *These utilities can be downloaded from ASRock Live Update & APP Shop.





  • Support CD

    - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar






  • Accessories

    - Quick Installation Guide, Support CD, I/O Shield
    - 2 x SATA Data Cables
    - 1 x Screw for M.2 Socket






  • Hardware Monitor

    - CPU/Chassis temperature sensing
    - CPU/Chassis Fan Tachometer
    - CPU/Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature)
    - CPU/Chassis Fan multi-speed control
    - CASE OPEN detection
    - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore






  • Form Factor

    - ATX Form Factor: 12.0-in x 8.2-in, 30.5 cm x 20.8 cm
    - Solid Capacitor design






  • OS

    - Microsoft® Windows® 10 64-bit (For 7th Gen Intel® CPU)
    - Microsoft® Windows® 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit (For 6th Gen Intel® CPU)

    *To install Windows® 7 OS, a modified installation disk with xHCI drivers packed into the ISO file is required. Please check our User Manual for more detailed instructions.





  • Certifications

    - FCC, CE


.
Typ pamäťového modulu
DDR4
Rozhranie
DVI
Socket (pätica)
Socket 1151
Formát
ATX
Integrovaná grafická karta
Ano (CPU)
Chipset
Intel
PCI express 16x
1
Integrovaná LAN karta
1
Podpora RAID
Bez RAID podpory
